Compresor cu șurub APS 7.5 IVR Combi Dry X 10 bar 7.5 CP/5.5 kW 170-760 l/min 200 l
Stoc epuizat
The APS 7.5 CombiDry compressor from Airpress has a capacity of 7.5 hp and 5.5 kW. At 10 bar the compressor has a capacity of 690 liters per minute, at 7 bar the compressor has a capacity of 770 liters per minute. This compressor is suitable for companies with low air consumption where nowadays a piston compressor is often used. The APS 7.5 CombiDry X measures 145 x 70 x 148 cm (l x w x h) and weighs 280 kg.
- Aveți nevoie de ajutor? Contactați-ne!
- Datorită cunoștințelor noastre, aveți cel mai bun produs.
- Livrare în 2-3 zile
- Peste 65 de ani de experiență pe piața europeană!
Detalii produs
| SKU | 369957-IVR |
|---|---|
| EAN 13 | 8712418372335 |
| Lungime (mm) | 1450 |
| Lățime (mm) | 670 |
| Înălțime (mm) | 1474 |
| Greutate (kg) | 280,00 |
| Sarcină de lucru (muncă/odihnă %) | 100/0 |
| Puterea motorului (cp / kW) | 7.5 HP / 5.5 kW |
| Clasa de eficiență a motorului | IE3 |
| Tip motor | PM Synchronous Motor |
| Antrenare | Direct driven 1:1 |
| Panou de control | MAM-6080 |
| Limbi disponibile | English, Dutch, Polish, German |
| Uscător | Yes |
| Tensiune uscător (V) | 230 |
| Rezervor aer | Da |
| Capacitate rezervor aer (l) | 200 |
| Rezervor galvanizat | Nu |
| Presiune maximă (bar) | 10 |
| Presiune de tăiere (bar) | 6 |
| Livrare aer liber la 8 bar (l/min) | 760 |
| Livrare aer liber la 10 bar (l/min) | 690 |
| Livrare minimă de aer liber (l/min) | 170 |
|---|---|
| Livrare minimă de aer liber (m3/h) | 10.2 |
| Livrare maximă de aer liber (l/min) | 760 |
| Livrare maximă de aer liber (m3/h) | 45.6 |
| Nivel de zgomot dB (A) (0 m) | 63 |
| Nivel de zgomot dB (A) (4 m) | 43 |
| Tip priză | EU |
| Volum aer de răcire (m3/h) | 2300 |
| Conexiune principală de aer (") | 3/4 |
| Temperatura minimă ambiantă (°C) | 10 |
| Temperatura maximă ambiantă (°C) | 45 |
| Fără ulei | Nu |
| Capacitate ulei (l) | 6 |
| Etape | 1 |
| Pornire | Inverter |
| Tensiune (V) | 400 V / 50 Hz / 3 Ph |
| Clasificare IP | IP55 |
| Viteză variabilă (IVR) | Da |
| RPM minim 10 bar (rpm/Hz) | 1100 |
| RPM maxim 10 bar (rpm/Hz) | 1960 |
| Consum minim de energie 10 bar (kW/m3/h) | 9.4 |
| Consum maxim de energie 10 bar (kW/m3/h) | 10.8 |
Produs recomandat
Descriere produs
The APS 7.5 IVR Combidry X is a 5.5 kW direct driven screw compressor with variable speed and a yield of 170 to 760 liters per minute. This makes this machine unique and very versatile, especially for small air users who often still use a piston compressor. A permanent magnet synchronous motor makes the machine even more economical, especially in the low revs, so that the efficiency is significantly higher than with an asynchronous motor. Due to the compact design, this machine takes up little space, but it does have a 200-liter compressed air boiler and a cooling dryer. The direct drive ensures a 1 on 1 transfer from the electric motor to the screw block, so that no losses occur. All parameters can be read and adjusted in the menu of the very comprehensive but well-arranged controller which is equipped with a full color touchscreen. This allows the machine to be adjusted per situation for maximum efficiency. The service interval of 3,000 hours also ensures lower maintenance costs. This machine is very suitable for small companies that have variable air take-off but where a silent compressor with dry compressed air is required.
X series Screw compressors
By continuously investing in the development of our products, the Airpress Group presents a new series of screw compressors. The screw compressors are available from 5.5 kW to 37 kW. The APS X series is available in two versions: controlled at a fixed speed or speed. Machines of 15 kW are also available with a two-stage screw block. These versions have an increased performance with the same power consumption as a single-stage version. Depending on demand, these machines are available as a separate unit, mounted on a tank or mounted on a tank and equipped with a compressed air dryer. Compressors of the X series are characterized by a new generation of screw blocks. The direct drive avoids losses due to the transmission. Reliable and efficient, easy-to-use screw compressors ensure trouble-free operation at minimal costs. Equipped with a modern control panel, you can constantly monitor the screw compressor and change parameters if necessary.
